Choice of thermally broken, heavy-duty all aluminum exterior and interior, or thermally broken, heavy-duty aluminum exterior and wood interior

Stacking lift & slide system aligns all panels with the stationary panel when in the fully open position; all panels are visible

Pocket lift & slide system incorporates a pocket into the wall cavity to conceal all panels when they are in the fully open position

Door jamb widths vary depending on the number of panels in the lift & slide door system and the handing

Up to five panels in any one direction, and 10 panels for a bi-parting lift & slide door

2-3/8" thick panel construction

Narrow 3-3/16" wide panels to reveal more glass for beautiful views

Standard panel heights: 8-0, 9-0, 10-0, 11-0 and 12-0

Standard panel widths: 3-0, 4-0, 5-0 and 6-0

Maximum panel sizes: 5-0 x 12-0 and 6-0 x 10-0

Standard 1-1/8" surface mount sill with 2-1/2" recessed sill with or without drainage

Two 2-wheel carriages engineered to provide maximum support

Nylon rollers combined with stainless steel ball bearings provide effortless operation

Multi-point locking system

Lead panel on pocket doors comes with a finger pull
